Part I Head, Neck, Brain and Spinal Cord
Brain, median sagittal section, with arachnoid covering intact – from the right
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
Basilar artery
Body of fornix
Splenium of corpus callosum
Anterior inferior cerebrellar artery
Paracentral artery
Medial frontobasal artery
Left vertebral artery
Genu of corpus callosum
Fourth ventricle
Body of corpus callosum
Callosomarginal artery
Parieto-occipital branch of posterior cerebral artery
Optic nerve (II)
Anterior lobe of cerebellum
Posteromedial frontal artery
Calcarine branch of posterior cerebral artery
Intermediomedial frontal artery
Pericallosal artery
Anteromedial frontal artery
Anterior cerebrellar artery
Pons
Cerebellar hemisphere
Precuneal artery
Pineal body
Mamillary body
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
Left vertebral artery
Anterior inferior cerebrellar artery
Basilar artery
Anterior cerebrellar artery
Medial frontobasal artery
Callosomarginal artery
Pericallosal artery
Anteromedial frontal artery
Intermediomedial frontal artery
Posteromedial frontal artery
Paracentral artery
Precuneal artery
Parieto-occipital branch of posterior cerebral artery
Calcarine branch of posterior cerebral artery
Cerebellar hemisphere
Anterior lobe of cerebellum
Fourth ventricle
Pons
Mamillary body
Optic nerve (II)
Body of fornix
Genu of corpus callosum
Body of corpus callosum
Splenium of corpus callosum
Pineal body
