Part III Upper Limb
Coronal section through the left wrist joint and hand – from behind
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
Base of proximal phalanx of little finger
Articular disc (triangular fibrocartilaginous complex, TFCC)
Capitate
Abductor digiti minimi
Extensor pollicis brevis
Trapezoid
Radial artery
Tendon of flexor digitorum profundus of index finger
Digital fibrous sheath of ring finger
Triquetral
Trapezium
Tendon of flexor digitorum profundus
Distal opening of carpal tunnel
Head of ulna
Head of first (I) metacarpal bone
Tendon of flexor digitorum superficialis
Abductor pollicis longus
Hamate
Abductor pollicis
Base of fifth (V) metacarpal bone
Pronator quadrates
Lunate
Flexor digitorum minimi
Flexor digitorum profundus
Styloid process of radius
Extensor pollicis longus
Shaft of radius
Tendon of flexor digitorum superficialis of index finger
Flexor pollicis longus
Scaphoid
Second lumbrical
Common digital artery and nerve
Distal end of radius
Shaft of ulna
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
Shaft of radius
Flexor pollicis longus
Flexor digitorum profundus
Shaft of ulna
Pronator quadrates
Head of ulna
Distal end of radius
Styloid process of radius
Abductor pollicis longus
Extensor pollicis brevis
Scaphoid
Lunate
Articular disc (triangular fibrocartilaginous complex, TFCC)
Triquetral
Trapezium
Radial artery
Trapezoid
Capitate
Hamate
Base of fifth (V) metacarpal bone
Distal opening of carpal tunnel
Abductor digiti minimi
Flexor digitorum minimi
Base of proximal phalanx of little finger
Digital fibrous sheath of ring finger
Common digital artery and nerve
Tendon of flexor digitorum superficialis
Tendon of flexor digitorum profundus
Second lumbrical
Abductor pollicis
Extensor pollicis longus
Head of first (I) metacarpal bone
Tendon of flexor digitorum profundus of index finger
Tendon of flexor digitorum superficialis of index finger
